Nylon Sunglasses Lens Gradient Blue Tinted
Engineered Optical Excellence
Every lens inherits five core performance pillars — from optical purity to impact safety.
Supreme Optical Clarity
Engineered exclusively as 0.00D Plano Lenses with an Abbe Value of 52, rivaling crown glass for ultimate optical purity. Low internal stress design guarantees minimal optical distortion and zero edge color fringing.
Seamless Dual-Zone VLT
High-Temp Precision Dip-Dyeing achieves a flawless transition from Top CAT 3 (8-18% VLT) for glare blocking to Bottom CAT 2 (18-43% VLT) for near-field clarity. Strictly controlled batch symmetry with Delta E < 1.0 and zero visible color banding.
Ultra-Lightweight & Crack Resistant
Specific Gravity of 1.01 for a truly weightless wearing experience. Delivers exceptional mechanical stability, absolutely immune to edge chipping during CNC drilling and slotting for rimless designs.
UV400 Full Protection
Offers uncompromised 100% blockage of UVA and UVB rays (≤400nm, ≥99% blocking) consistently across both the dark and light transition zones.
Precision Alignment Marks
To solve the industry pain point of tilted gradient lines during CNC edging, all gradient blanks feature high-precision, washable eco-ink horizontal axis lines. This completely eliminates alignment defects and maximizes your rimless assembly yield rate.
Nylon Sunglasses Lens Gradient Color Blue Tinted
Click to play and see the optical performance and real-world clarity of our blue gradient nylon sunglass lenses — showcasing the seamless CAT 3-to-CAT 2 tint transition.
Technical Specifications
| Material | Optical Grade Nylon (Polyamide) |
| Color | Couture Gradient Blue (Pantone matching available) |
| VLT / Category | CAT 3: 8-18% (Top / Dark Zone) / CAT 2: 18-43% (Bottom / Light Zone) |
| UV Protection | UV400 (≤400nm, ≥99% blocking) |
| Abbe Value | 52 |
| Specific Gravity | 1.01 g/cm³ |
| Optical Accuracy | Plano 0.00D; Residual Astigmatism ≤0.09D; Residual Prism ≤0.12Δ, measured at the optical reference point. |
| Base Curve | 2C / 4C / 6C / 8C Available |
| Center Thickness | 1.5mm - 2.0mm (±0.05mm) |
| Diameter | 71mm / 75mm / 80mm (custom available) |
| Impact Test | FDA 21 CFR 801.410 Pass |
| Certifications | CE / FDA / UKCA / GB / ANSI / EN / AS/NZS |
| MOQ | 300 Pairs/Specification |
| Origin | Shenzhen, China |
| Logo | Laser engraving (recommended for gradient lenses), Screen printing, UV printing, Decal, Embedded logo |
Production-Ready Integration
Everything you need to source with confidence
- Acetate Frames — Highly recommended. Excellent chemical resistance against acetate plasticizers. Completely immune to stress cracking caused by Acetate's cooling shrinkage during fitting.
- Rimless / Drill-mount — Supreme tensile strength ensures zero edge chipping during CNC drilling and slotting.
- Titanium / Carbon Fiber / Metal / TR90 Frames — Optimal compatibility, lightweight and corrosion-resistant, ideal for premium eyewear frame designs.
- Pantone matching for precise gradient base colors and bi-color transitions (e.g., Sunset Gradient)
- Custom gradient zone ratio — dark zone depth adjustable (e.g., top 40% / bottom 60% of lens height)
- B-AR (Back-Surface AR) coating recommended to eliminate rear reflections
- Coating upgrades: HC / Oleophobic / Hydrophobic / Anti-fog
- Simple Packaging: PE bag + white box, Premium Packaging: Individual color box + cloth bag, Blister: Transparent blister box, Custom: Brand LOGO packaging
- MOQ: 300 Pairs/Specification
- Sample Lead Time: 7–10 working days, allowing you to verify gradient quality before bulk order
- Bulk Lead Time: 15–20 working days (subject to quantity and customization complexity)
- Custom Options: Pantone color matching, custom VLT zone ratio, dark-zone depth control, bi-color gradient transitions, B-AR coating, OEM/ODM laser logo, custom packaging
- Reports: Light Transmittance Test Report, UV Blocking Test Report, Impact Resistance Test Report, Color Consistency (Delta E) Test Report, Salt Spray Test Report
Features & Applications
Technical Features
- Optical Clarity: An Abbe Value of 52 provides visual purity that closely rivals crown glass. This high-grade nylon foundation completely eliminates the optical distortion responsible for end-user returns.
- Tint Precision: High-temp dip-dyeing maintains a highly consistent Top CAT 3 to Bottom CAT 2 gradient fade. Strict batch color control (Delta E < 1.0) reliably prevents rejected shipments during final frame assembly.
- Comprehensive UV Protection: Uncompromised 100% blockage of UVA and UVB rays (≤400nm) remains constant across both the dark and light zones. This strict adherence to global safety standards insulates your business from regulatory liabilities.
- Assembly Efficiency: The ultra-low specific gravity of 1.01 g/cm³ delivers exceptional mechanical stability. This structural strength drastically cuts material scrap by preventing edge chipping during rimless CNC drilling.
- Impact Certification: Rigorous FDA 21 CFR 801.410 drop-ball testing guarantees robust shatter resistance. This verifiable mechanical durability directly minimizes post-sale warranty claims for premium eyewear collections.
- Flexible Scalability: Independent Eyewear Designers can easily prototype specialized frame interfaces using available 2C to 8C base curves. Custom Pantone matching and adjustable gradient zone ratios are highly accessible at a 300-pair MOQ.
Perfect For
- Premium Eyewear Brands
- Independent Eyewear Designers
- Private Label Distributors
- Lens Distributors
- Department Store Groups
- E-commerce D2C Brands
Dual-Zone VLT Reference
| Gradient Zone | VLT (%) | Category | Usage Environment |
|---|---|---|---|
| Top (Dark Zone) | 8% - 18% | CAT 3 | Direct sunlight, outdoor glare blocking |
| Bottom (Light Zone) | 18% - 43% | CAT 2 | Near-field clarity, reading, driving view |
Note: The gradient transition is continuous with zero visible banding. Delta E < 1.0 batch-to-batch consistency is enforced at the factory level.
Overview
A gradient lens must carry a flawless visual fade to preserve the aesthetic intent of a flagship design. This optical-grade tinted component provides a reliable transition that filters direct glare while keeping lower-field vision clear.
Tighter color control and faster sample turnaround come from a fully integrated production chain, ensuring the shade your team signs off on is the lens your factory ships. Custom fade ratios and tailored coating stacks are the customization baseline—every spec carries from your brief to the finished sample without compromise, all built under one roof in Shenzhen.
Precision Dip-Dye Manufacturing — How Xinxin Crafts Gradient Nylon Sunglass Lenses in Shenzhen
Click to play and see how our blue gradient nylon lenses are precision dip-dyed and quality-controlled — from blank forming through dual-zone tint verification.
International Quality Standards
Active certifications — verified & compliant
.webp)
Ready to Elevate Your Sunglass and Goggles Lenses?
Partner with XinXin Optics for premium custom lens manufacturing. We offer competitive MOQs and industry-leading lead times, specifically tailored for global brands.
Start Your Project
Submit your project information, and our engineering team will deliver a detailed preliminary review within 24 hours.
Thank You!
Your inquiry has been sent successfully. We will contact you within 24 hours.
Or contact us directly:
