Nylon Sunglasses Lens Gray Silver Mirror Coated
Engineered Optical Excellence
Every lens inherits five core performance pillars — from optical purity to impact safety.
Supreme Optical Clarity
Engineered exclusively as 0.00D Plano Lenses with an Abbe Value of 52. Low internal stress design guarantees minimal optical distortion and zero edge color fringing, even on base 8+ shield lenses.
True REVO Dielectric Coating
Utilizes 12-14 layers of nano-scale Ion-Assisted E-Beam Evaporation in a Class 10,000 cleanroom, delivering a high-saturation Nylon Sunglasses Lens Gray Silver Mirror Coated finish that efficiently cuts off side and bottom glare.
Premium Hard-Coating Prerequisite
A high-density hard-coating securely anchors the brittle REVO layers to the flexible nylon base. This achieves Grade 0 cross-cut adhesion (ASTM D3359), completely preventing cracking or peeling under extreme frame-fitting tension.
Strict Color Consistency
Automated spectrophotometer monitoring ensures absolute batch-to-batch REVO reflection consistency with a strictly controlled Delta E < 1.2, eliminating visual discrepancies in bulk orders.
Super Hydrophobic & Oleophobic
Standard upgraded outer layer featuring a water contact angle > 110°. Effortlessly repels water, sweat, and fingerprints, maintaining pristine mirror reflections during intense activities.
Nylon Sunglasses Lens Gray Silver Mirror Coated
Click to play and see the optical performance and real-world clarity of our Nylon Sunglasses Lens Gray Silver Mirror Coated — showcasing the high-saturation reflective finish and pure optical clarity.
Technical Specifications
| Material | Optical Grade Nylon (Polyamide) |
| Color | Nylon Sunglasses Lens Gray Silver Mirror Coated (REVO) |
| Coating Method | 12–14 Layer Ion-Assisted E-Beam Evaporated Dielectric Gray Silver Mirror Coating |
| VLT / Category | 8-18% / CAT 3 |
| UV Protection | UV400 (≤400nm, ≥99% blocking) |
| Abbe Value | 52 |
| Specific Gravity | 1.01 g/cm³ |
| Optical Accuracy | Plano 0.00D; Residual Astigmatism ≤0.09D; Residual Prism ≤0.12Δ, measured at the optical reference point. |
| Base Curve | 2C / 4C / 6C / 8C Available |
| Center Thickness | 1.5mm - 2.0mm (±0.05mm) |
| Diameter | 71mm / 75mm / 80mm (custom available) |
| Impact Test | FDA 21 CFR 801.410 Pass |
| Certifications | CE / FDA / UKCA / GB / ANSI / EN / AS/NZS |
| MOQ | 300 Pairs/Specification |
| Origin | Shenzhen, China |
| Logo | Laser engraving, Screen printing, UV printing, Decal, Embedded logo |
Production-Ready Integration
Everything you need to source with confidence
- Acetate Frames — Highly Recommended. Excellent chemical resistance against acetate plasticizers. Completely immune to stress cracking caused by Acetate's cooling shrinkage during fitting. The REVO coating remains firmly anchored under high rim tension.
- Rimless / Drill-mount — Supreme tensile strength ensures zero edge chipping during CNC drilling and slotting.
- Titanium / Carbon Fiber / Metal / TR90 Frames — Optimal compatibility, lightweight and corrosion-resistant, ideal for premium eyewear frame designs.
- Pantone matching for precise base tint colors
- Exclusive REVO mirror color development (e.g., Fire Red, 24K Gold, Ice Blue)
- B-AR (Back-Surface AR) coating strictly recommended to eliminate rear ghost reflections
- Coating upgrades: Anti-Seawater / Anti-static / Premium Hard-Coating / Anti-Oleophobic / Anti-Hydrophobic / Anti-fog
- Simple Packaging: PE bag + white box, Premium Packaging: Individual color box + cloth bag, Blister: Transparent blister box, Custom: Brand LOGO packaging
- MOQ: 300 Pairs/Specification
- Sample Lead Time: 7–10 working days, allowing you to verify mirror coating quality before bulk order
- Bulk Lead Time: 15–20 working days (subject to quantity and customization complexity)
- Custom Options: OEM/ODM, Pantone matching, custom REVO colors, laser logo, custom packaging
- Reports: Light Transmittance Test Report, UV Blocking Test Report, Impact Resistance Test Report, Color Consistency (Delta E) Test Report, Salt Spray Test Report
Features & Applications
Technical Features
- Optical Purity: An Abbe Value of 52 rivals crown glass for clarity, while low internal stress guarantees minimal distortion. This high-grade nylon base completely prevents edge color fringing that often drives customer returns for premium eyewear brands.
- Precision Mirror Coating: Consistent batch-to-batch reflections for our Nylon Sunglasses Lens Gray Silver Mirror Coated are achieved through 12-14 layer Ion-Assisted E-Beam Evaporation (PVD) and strict Delta E < 1.2 monitoring. This advanced dielectric coating process eliminates supply chain delays caused by mismatched lenses.
- UV400 Compliance: We guarantee 100% blockage of UVA and UVB rays (≤400nm). Your business is fully shielded from regulatory roadblocks and liability risks across global markets.
- Manufacturing Efficiency: Edge-chipping during CNC drilling is virtually eliminated. An ultra-low specific gravity of 1.01 g/cm³ combined with grade 0 cross-cut adhesion (ASTM D3359) delivers the mechanical stability needed to lower material scrap rates during assembly.
- Mechanical Safety: Reliable shatter resistance minimizes post-sale warranty claims. These lenses strictly comply with the FDA 21 CFR 801.410 drop-ball test to provide robust safety for end users.
- Scalable Customization: E-commerce D2C Brands can easily test new collections with tailored base curves (2C–8C) and custom diameters up to 80mm. Exclusive REVO mirror color development is accessible starting at a highly competitive 300-pair MOQ.
Perfect For
- Premium Eyewear Brands
- Independent Eyewear Designers
- Private Label Distributors
- Sports & Automotive Lifestyle Labels
- Luxury Fashion Houses
- E-commerce D2C Brands
Overview
Our Nylon Sunglasses Lens Gray Silver Mirror Coated features a neutral gray base tint paired with a high-saturation reflective silver mirror finish to deliver the high-contrast aesthetic that defines modern sunwear. The mirror layer blocks intense surface glare while the base tint maintains true color recognition and visual comfort in bright conditions.
Optical-grade construction guarantees reliable impact safety, ensuring your collection avoids the warranty claims associated with heavier, more fragile components. The customization workflow takes a coating reference and returns a signed-off prototype—matched tint and tailored coating stack, all built in-house at Xinxin.
Lens Category
| Category | VLT (%) | Usage Environment |
|---|---|---|
| CAT 0 | 80% - 100% | Indoor or overcast low-light conditions |
| CAT 1 | 43% - 80% | Low-light outdoor, overcast |
| CAT 2 | 18% - 43% | Medium light, daily outdoor |
| CAT 3 | 8% - 18% | Strong outdoor light, sunny |
| CAT 4 | 3% - 8% | Extreme light, e.g., skiing, mountaineering |
12-14 Layer Ion-Assisted E-Beam Evaporation (PVD) — How Xinxin Crafts REVO Mirror Lenses
Click to play and see how our Nylon Sunglasses Lens Gray Silver Mirror Coated is manufactured using nano-scale Ion-Assisted E-Beam Evaporation in a Class 10,000 cleanroom.
International Quality Standards
Active certifications — verified & compliant
.webp)
Ready to Elevate Your Sunglass and Goggles Lenses?
Partner with XinXin Optics for premium custom lens manufacturing. We offer competitive MOQs and industry-leading lead times, specifically tailored for global brands.
Start Your Project
Submit your project information, and our engineering team will deliver a detailed preliminary review within 24 hours.
Thank You!
Your inquiry has been sent successfully. We will contact you within 24 hours.
Or contact us directly:
